EB-L630U Full HD WUXGA Laser Projector

The ultra bright WUXGA projector for classrooms, meetings and more

Share bright, easy-to-read displays for meetings, lectures and more with the EB-L630U long-throw laser projector. Offering an incredible 6,200 lumens of brightness1, the EB-L630U enhances spaces with vibrant, true-to-life, Full HD WUXGA images. Ideal for business, education and beyond, this versatile projector displays up to 500" and provides an array of features for engaging, impactful experiences, including integrated wireless networking and Miracast® for easy sharing from laptops and smart devices2. A convenient, easy-to-use solution, the  EB-L630U features a virtually maintenance-free 20,000-hour laser light source3, plus a variety of built-in tools, lens shift and advanced software for easy, streamlined installation.

    • • Up to 6,200 lumens of equal Color and White Brightness1
      • Full HD WUXGA support; accepts 4K signal
      • Virtually maintenance-free 20,000-hour laser light source3
      • Display from 50" to 500" diagonal (16:10) or ultra wide (16:6)
      • Built-in tools for simplified installation



3-chip 3LCD image quality
With up to 6,200 lumens of equal Color and White Brightness1 for vibrant, rich color

Full HD WUXGA support
Native WUXGA 1920 x 1200 resolution for true-to-life images; accepts 4K signal

Breakthrough laser technology
Features a virtually maintenance-free 20,000-hour laser light source3

Flexible projection
Lightweight, easy-to-install design; can display images from 50" to 500" diagonal in 16:10 or ultra wide 16:6 to cover a large wall with bold, beautiful images

Convenient placement
Easy installation and flexible placement with horizontal and vertical lens shift

Integrated wireless networking with enterprise-level security
Additionally, you can connect with Miracast, which supports software-free, peer-to-peer wireless connectivity; screen sharing for remote collaboration.

Simplified installation
3
60-degree flexibility, 1.6x optical zoom, e-zoom; geometric correction tools such as horizontal and vertical keystone, edge blending, arc correction, Quick Corner® and more

Variety of connectivity options
HDBaseT™, HDMI®, HDMI Out, VGA, RJ-45, RS-232 and control management tools

Remarkable sharpness and detail
Get up to 50,00,000:1 dynamic contrast ratio

Custom brightness and constant brightness modes
 Maximize light source life and provide a consistent brightness level



What's in the box:

  • EB-L630U Projector
  • Power Cable
  • Computer Cable (HDMI)
  • Projector Remote Control with Batteries
  • Quick Setup Sheet
  • Cable Cover
  • Quick Setup Poster

Projection Technology:


Projection Technology: RGB liquid crystal shutter projection system

Connectivity:


Network Protocol: HTTPS, IPv6, SNMP, ESC/VP.net, PJLinkInterface: USB 2.0-A, USB 2.0, RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac, Wireless LAN b/g/g 25GHz, Wireless LAN a/n (5GHz), VGA in (2x), VGA out, HDMI out, HDBaseT, Miracast, Jack plug out, Jack plug in (2x), HDMI (HDCP 2.3) (2x), USB 2 Type A playback

Projection Lens:


Zoom Ratio: 1-1.6 (Manual)

Wireless Specifications (Wireless LAN: Built-in):


Supported Connection Mode: Infrastructure, Access Point

Direct Power On/Off:


Direct Power On/Off: Yes

Specifications Projector:


Aspect Ratio: 16:10Native Resolution: WUXGA

Main Parts Specification:


Light Source: Laser Light Life: 20,000 hours

Long Throw Zoom Lens:


Screen Size (Projected Distance): 50 inches - 500 inchesLens Shift Range: Manual - Vertical ± 50 %, horizontal ± 20 %

Direct Power On / Off:


Direct Power On / Off: Yes

Projectors Facets:


Resolution, Projectors Facets:  WUXGA and Full HD supportThrow Ratio: 1.35-2.20Brightness Range Lumens, Projectors Facets: 7000Laser / Lamp, Projectors Facets: Laser diode

Brightness:


Colour Light Output: 6.200 Lumen- 4.340 Lumen (economy) In accordance with IDMS15.4White Light Output: 6.200 Lumen - 4.340 Lumen (economy) In accordance with ISO 21118:2020Contrast Ratio: Over 50,00.000 : 1Light Output (Center): 6500

Notes:

 Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118.
2 For wireless functionality, including via the Epson iProjection™ App, the projector must be configured on a network, either through the Ethernet port on the projector (check model specifications for availability) or via a wireless connection. Check your owner’s manual to determine if a wireless LAN module must be purchased separately to enable a wireless connection. Not all Epson projectors are able to be networked. The Epson iProjection App does not support all files and formats. See www.epson.co.in  for details.
3 No required maintenance for the light source for up to 20,000 hours. Approximate time until brightness decreases 50% from first usage. Measured by acceleration test assuming use of 0.04 - 0.20 mg/m3 of particulate matter. Time varies depending on usage conditions and environment.

*This light output value is measured at the centre of the screen as a reference value. There is no official standard for light output (Centre) measurements and this measurement is made based on the method set by Epson.
