Epson ColorWorks C6550P Peel-and-Present Colour Label Printer

Labelling Solutions Made Convenient

Redefine productivity with Epson’s ColorWorks C6550P colour label printers. Integrated with print-and-apply peeler capabilities, the hassles of manual removing of label backing papers is eliminated. The peeler feature is ideal for on-demand print-and-apply colour label printing installations. Beyond efficient functionalities, the ColorWorks printer deliver quality prints with crisp images that are sure to impress any audience.

      • 203.2mm (8-inch) Colour Label On-Demand Printer
      • Peeler function for print-and-apply label applications
      • Seamless connectivity for easy integration across multiple platforms
      • Astounding print quality of 1200dpi


Enhanced Production Capability
The C6550P’s peel-and-present model improves efficiency and convenience by eliminating the need for manual peeling. When integrated with a print-and-apply system through the use of label applicators, a more seamless workflow experience is enabled, enhancing productivity in the production line.

Crisp Images
A higher dpi translates to a clearer, more detailed output. With a print resolution of up to 1200 dpi, variable droplet size and Spot Colour Matching* that assures greater colour accuracy, the C6550P ColorWorks label printers series produce incredible print images.

High Connectivity
Compatible with a wide range of technologies including multiplatform operating systems such as Windows, Mac and Linux along with application software including SAP and legacy systems using ZPL II commands, the set-up process becomes effortless and can be integrated into nearly any workflow seamlessly.

World’s First Peeler-equipped Inkjet Label Printer
Making it possible to apply labels immediately after printing, the C6550P can be used in any desktop printing operations. When integrated with a label applicator in the production floor, it offers unique print-and-apply system that can be used both online and offline.

Easy Use and Maintenance
Intuitive designs including easy-load spindle, flexible paper cover and frontal ink cartridge loading allows for quick changes between label sizes, easy access when loading paper and effortless replacement of ink cartridges. Equipped with a 2.7” colour LCD, printer status can be checked and configured when required. Enjoy seamless installation in a variety of environments with the ColorWorks’ space-saving design.

Durable, Exceptional Quality Inks
The ColorWorks C6000 series incorporates UltraChrome DL pigment inks that comply with BS 5609 certification for GHS compliant labelling. These inks possess high pigment density, resin coating for more stability, and an even surface and gloss, making it perfect for professional display and sales.

PrecisionCore TFP Printhead
With its stunning ability to scale while delivering unbeatable speed and precision, the printhead’s perfectly round nozzles dispense precise ink droplets, which guarantee consistent superior image quality.


Interface: USB2.0, Ethernet 1000Base-T / 100Base-TX / 10Base-T Extended Interface: Dsub-25pin

Print Fonts:

Print Fonts: Built-in font available

Printing Technology:

Print Speeds: Matte Paper Label, Synthetic Label: Max Speed (300 x 600 dpi): 85mm/s, Speed (600 x 600 dpi): 49mm/s, Normal (600 x 600 dpi): 34mm/s, Quality (600 x 1200 dpi): 13mm/s *When printing 203.2mm width; Glossy Paper Label, Glossy Film Label, High Glossy Paper Label Normal (600 x 600 dpi): 34mm/s, Quality (600 x 1200 dpi): 13mm/s, Max quality (1200 x 1200 dpi): 6mm/s *When printing 203.2mm widthTechnolgy: Serial Inkjet PrecisionCore TFP® with Nozzle Verification TechnologyColour: Four-colour printing, individual ink cartridge (UltraChromeTM DL pigment ink: C, M, Y, K)

Ink Cartridge:

Colour: Cyan, Magenta, Yellow, BlackModel: SJIC40P-BK / SJIC40P-C / SJIC40P-M / SJIC40P-Y

Media Type:

Media Type: Matte paper label, Synthetic label, Glossy paper label, Glossy film label, High glossy paper label

Barcode Font (Printer Driver Built-in):

Barcode: UPC-A, UPC-E, JAN13(EAN), JAN8(EAN), Code39, ITF, Codabar, Code93, Code128, GS1-128, GS1 DataBar, Omnidirectional, GS1 DataBar Truncated, GS1 DataBar Limited, GS1 DataBar ExpandedTwo-dimensional Code: PDF417, QR Code, Maxi Code, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, GS1 DataBar, Expanded Stacked, DataMatrix, Aztec Code, MicroPDF417, Micro QR Code

Rated Voltage:

Rated Voltage: AC 100 - 240 VAC

Rated Frequency:

Rated Frequency: 50 - 60Hz

Operating System:

Operating System: Windows 10, 8.1, 8, 7 SP1, Vista SP2, XP SP3 or later, Server 2019, 2016, 2012 R2, 2012, 2008 R2, 2008, 2003 R2 (32-bit), Mac OS X 10.6.8, Mac OS X 10.7.x, Mac OS X 10.8.x, Mac OS X 10.9.x, Mac OS X 10.10.x, Mac OS X 10.11.x, Mac OS X 10.12.x, Mac OS X 10.13.x, Mac OS X 10.14.x

Media Source:

Media Source: Roll media, Fanfold

Temperature / Humidity:

Printing: Printing: 5 to 35°C / 20 to 80% RH; Barcode Printing: 15 to 35°C, 20 to 80% RHStorage: When packed (ink not charged): -20 to 60°C / 5 to 85% RH Humidity (no condensation)

Overall Dimensions:

Overall Dimensions: 444 x 515 x 326mm (W x D x H, not including protrusion)

Media Form:

Roll: Continuous label (BM or w/o BM), Die-cut label (Gap or BM)Fanfold: Die-cut label (BM)


* Spot colour matching is subjected to the printer’s ink spectrum capability.
