Epson Home TW5820 3LCD 1080p Streaming Projector


Make your home the centre stage for all the action with this Full-HD 1080p projector that’s complete with gaming features. With Android TVTM*1, you can easily stream and cast entertainment to a smart and flexible display solution. Sharp images, deep blacks, smooth movement and great connectivity along with easy setup and alignment make this projector the ultimate choice for home entertainment.

      • Stunning Full-HD 1080p visuals
      • Smooth, clear images
      • Built-in Android TVTM*1
      • Vertical lens shift
      • 2,700 lumens of colour and white brightness*2



Big screen experience
With this Full-HD 1080p home theatre projector, you can create the big screen experience with images in sizes up to 762 cm (300 inch). It can handle the most atmospheric scenes with clearly defined shadows and deep blacks while also maintaining clarity, sharpness and seamlessness with detail enhancement and frame interpolation. Stay immersed and play games as they should be played with dark gamma uplift. Increase the brightness to capture every detail and extend your resolution to 21:9 for a rich gaming experience.

Bright and beautiful images
Sit back, relax and revel in the beauty of our projected displays. Our projectors incorporate a range of high-tech features that work seamlessly behind the scenes to deliver awe-inspiring images. Epson’s 3LCD technology, which ensures up to three times brighter colours than 1-chip DLP projectors, provides exceptionally bright yet colourful images by producing an equally high white and colour light output. Even in bright living rooms, this Full-HD 1080p projector delivers images in up to 2,700 lumens and at a contrast ratio of 70,000:1.

Expand the possibilities
With Android TV™*1, you can easily stream and cast entertainment, talk to Google Assistant* and share content from your phone to a smart and flexible display solution.

Powerful speaker
Enjoy dynamic audio from the built-in 10W speaker or simply connect to a soundbar, Bluetooth speaker or headphones with Bluetooth AptX.

Long-lasting solution
Looking for a long-term, hassle-free and affordable solution for your entertainment needs? With the EH-TW5820, you can watch a film every day for up to 11 years thanks to its reliable lamp light source*³.

Flexible placement
The 1.6x zoom, horizontal keystone correction function and lens shift functions enable flexible placement even in a confined space.

Projection Technology:

Projection Technology: RGB liquid crystal shutter projection system

Screen Size (Projected Distance):

Standard Size: 80” screen 2.35-3.82mZoom : Wide: 30” - 300” [0.87-8.9m]Zoom : Tele: 30” - 300” [1.42 – 14.5m]


White Light Output (Normal): 2,700 lm / 1,780 lmColour Light Output: 2,700 lm

Contrast Ratio:

Contrast Ratio: 70,000:1

Geometric Correction:

Vertical/Horizontal Keystone: ±30° / ±30° (Slide Bar)Auto Keystone: Yes (Vertical)Horizontal Slide Keystone Correction: YesQuick Corner: Yes


USB Interface: USB Mini Type B: 1Digital Input: HDMI x 1 (HDCP 1.4)Audio Out: Stereo Mini Jack x 1Wireless: Built-inAndroid TV Dongle: Yes (Android 9.0. Nunai OS)

Operating Altitude:

Operating Altitude: 0 - 3,000 m <0 - 9,843 ft> (over 1,500m / 4,921ft: with high altitude mode)

Start-Up Period:

Start-Up Period: Under 15 seconds
Warm-up period: 30 seconds

Cool Down Period:

Cool Down Period: Under 5 seconds

Direct Power On/Off:

Direct Power On/Off: Yes / N/A

Fan Noise:

Fan Noise (Normal / Eco): 37dB / 27dB

Projection Lens:

Lens Shift: Vertical: +45% to +60%

Wireless Specifications (Wireless LAN: Built-in):

Wireless LAN Security: Quick: WPA2-PSK, Advanced: WPA/WPA2-PSKSupported Connection Mode: Infrastructure, Access Point

Adjustment Functions:

Aspect Mode: Yes (Auto / Normal / Full / Zoom)Frame Interpolation: Yes

Image Enhancement:

Detail Enhancement: Yes

Internal Speaker(s):

Sound Output: 10W Monaural

3D Features:

3D Display: Yes3D Format: Yes3D Depth: Yes2D - 3D Conversion: Yes

Dimension Excluding Feet:

Dimension Excluding Feet (D x W x H): 308 x 309 x 107 mm


*Google, Google Assistant, Google Play, YouTube, Android TV and other marks are trademarks of Google LLC.

*1 Android is a trademark of Google Inc. Requires wireless network connection of 5 Mbps or faster. Some apps require paid subscriptions.

*2 Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118.
*3  Based on watching an average 1hr 45mins film every day and the lamp set in Eco mode.
